When picking the right 2026 Ford F-150®, choosing the right engine is a key factor, and the lineup gives you six to consider. The range spans an efficient turbocharged 2.7L EcoBoost® V6, a fuel-saving 3.5L PowerBoost® full hybrid V6, and a supercharged V8 that tops the lineup. This guide breaks down each engine’s output, towing and payload capability, and trim availability so you can match the powertrain to how you drive and what you tow. Read on for a closer look at the 2026 Ford F-150 engine options with this engine and towing guide from the team at TERA Ford.
Stop by TERA Ford in Plano, IL, to see the lineup in person. If you have any questions, contact us online or call us at (630) 552-8058, and our team will help you find the right fit.
Navigate to a specific research section to learn more:
Six engines anchor the 2026 Ford F-150 lineup, spanning everyday efficiency, serious towing capability, and high-output off-road performance. The gas and hybrid engines handle daily driving and hard work, while the off-road Raptor® sits at the top, powered by a standard high-output V6 or an available supercharged V8 through the Raptor R™ Equipment Group.
View the following engine specifications for more information.
| Engine | 2.7L EcoBoost V6 | 5.0L Ti-VCT V8 | 3.5L EcoBoost V6 | 3.5L PowerBoost full hybrid V6 | High-output 3.5L EcoBoost V6 | 5.2L supercharged V8 |
|---|---|---|---|---|---|---|
| Horsepower | 325 HP | 400 HP | 382 HP | 420 HP | 450 HP | 720 HP |
| Torque | 400 lb.-ft. | 410 lb.-ft. | 500 lb.-ft. | 570 lb.-ft. | 510 lb.-ft. | 640 lb.-ft. |
| Transmission | Ten-speed automatic | |||||
| Drivetrain | 4×2 / 4×4 | 4×4 | ||||
| MPG (City/Hwy) | 19 / 25 | 16 / 24 | 17 / 25 | 22 / 24 | 16 / 21 | 10 / 15 |
The standard 2.7L EcoBoost V6 is the efficiency-minded starting point, using twin turbochargers to make 325 horsepower without a fuel-economy penalty. It is the everyday choice for commuting and lighter hauling.
A naturally aspirated V8, the 5.0L Ti-VCT delivers 400 horsepower and the traditional V8 feel many truck buyers want. It backs that character with a 12,800-pound tow rating when properly equipped.
Built for maximum towing, the 3.5L EcoBoost V6 generates 382 horsepower and pulls up to 13,500 pounds when properly equipped. Its twin-turbocharged torque makes it the pick for buyers who tow heavy on a regular basis.
The 3.5L PowerBoost full hybrid V6 is the only electrified engine in the lineup, pairing a twin-turbocharged V6 with an electric motor for 420 horsepower and strong efficiency. It also offers available Pro Power Onboard™ to run tools and equipment straight from the truck.
Reserved for the Raptor, the high-output 3.5L EcoBoost V6 is tuned for high-speed off-road performance, putting out 450 horsepower. Its twin-turbocharged output drives the long-travel suspension and desert-running hardware that define the Raptor.
Available on the Raptor through the Raptor R Equipment Group, the supercharged 5.2L V8 is the most powerful engine in the F-150 lineup, making 720 horsepower. The supercharger gives it immediate throttle response for high-speed desert running and demanding off-road performance.
Properly equipped, the 2026 Ford F-150 tows up to 13,500 pounds, a figure reached with the 3.5L EcoBoost V6 paired with the Tow/Haul Package and the available Max Tow Axle. That same engine leads the lineup in hauling, with up to 2,440 pounds of max payload. Available trailering technology takes some of the guesswork out of the job, including Pro Trailer Backup Assist™ and an integrated trailer brake controller.
View the following towing and payload capacities for more information.
| Engine | 2.7L EcoBoost V6 | 5.0L Ti-VCT V8 | 3.5L EcoBoost V6 | 3.5L PowerBoost full hybrid V6 | High-output 3.5L EcoBoost V6 | 5.2L supercharged V8 |
|---|---|---|---|---|---|---|
| Max. Towing Capacity | 8,400 lbs. | 12,800 lbs. | 13,500 lbs. | 12,400 lbs. | 8,200 lbs. | 8,700 lbs. |
| Configuration for Max. Towing | Reg. Cab, 8-ft. Bed, 4×2 | SuperCrew, 5.5-ft. Bed | SuperCrew, 6.5-ft. Bed, 4×4 | SuperCrew, 6.5-ft. Bed, 4×2 | SuperCrew, 5.5-ft. Bed | |
| Max. Payload Capacity | 1,775 lbs. | 2,235 lbs. | 2,440 lbs. | 1,740 lbs. | 1,405 lbs. | 1,410 lbs. |
The high-output and supercharged engines stay exclusive to the off-road Raptor, while the other four engines are spread across the rest of the trims in varying combinations. The gas engines reach the widest range of trims, and the PowerBoost full hybrid covers a broad span of its own.
View the following engine availability by trim for more information.
| Trim | 2.7L EcoBoost V6 | 5.0L Ti-VCT V8 | 3.5L EcoBoost V6 | 3.5L PowerBoost V6 | High-output 3.5L EcoBoost V6 | 5.2L Supercharged V8 |
|---|---|---|---|---|---|---|
| XL | ✓ | ✓ | ✓ | |||
| STX® | ✓ | ✓ | ✓ | |||
| XLT | ✓ | ✓ | ✓ | ✓ | ||
| Lariat® | ✓ | ✓ | ✓ | |||
| King Ranch® | ✓ | ✓ | ||||
| Platinum® | ✓ | ✓ | ||||
| Tremor® | ✓ | ✓ | ||||
| Raptor | ✓ | ✓ |
The Ford F-150 pairs a versatile engine lineup with the capability to handle work and weekends alike. Keep exploring our research to see how the trims and features come together.
